tCm
THE COLLIDER MACHINE
karl bucher ag PERELMANseries
THE CONCEPT
A vertical particle collider which minimizes its divergences with different time standards.
THE DESIGN
The design should convey the thought of time.
THE CASE
Grown over time, sustainable, conceptualized and realized with reference to unique high-end craftsmanship together with our cooperation partner.
Surfaces in mirrored walnut burl real wood veneer. Executed on three levels in a Dirichlet decomposition in points that define the spaces between them.
Copper shielded display zone.
Three wing doors, invisibly closed with badge locking system.
Ring bezel in walnut solid wood tangentially divided into 12 segments. The back is 12-segment tangentially veneered in walnut and has a milled Dirichlet decomposition.
The internal vertical radial hull rips are solid walnut. All surfaces inside as well as outside are transparent high gloss lacquered.
THE ATOMIC CLOCK
The standard output frequency of the first rubidium reference (MIL-SPEC) in the low 10-12 range (ADEV | 1 sec) is routed clockwise over the length of 631 cm in a circle.
The standard output frequency of the second rubidium reference in the low 10-12 range (ADEV | 1 sec) is conducted counterclockwise over the length of 631 cm in a circle.
At the interface, the two standard frequencies collide in the cross-correlator. A new standard frequency is created without divergence of the two output standard clocks.
This whole unit forms the basic clock of the atomic clock.
For the start-up procedure and the readout of the coordinated atomic clock time under consideration of the earth rotation (MSF/GBZ with dUT 1), as well as the basic clock for the entire logic and its algorithm, an oven-controlled crystal reference in the low 10-12 range (ADEV | 1 sec) is responsible. This clock unit performs its work in a separate zone in the atomic clock.
This unit forms the auxiliary clock.
THE OPERATING STATUS INDICATOR
An original flywheel unit from the tri-axial inclination control system of the UKube-1 satellite of the AAC Clyde Space Laboratory. The torque positioning reaction wheel acts in non-stop operation as a widely readable supply indicator and filter for the atomic clockworks (physics and electronics packages).
THE DISPLAY SYSTEM
Dual system in blocks, placed in ascending order (seconds, minutes, hours, days, months, years). Within each block arranged in reverse sequenced descending number units. Each number unit exclusively recognizes only the two operating states on (1) and off (0).
THE POWER SUPPLY
An analog power supply with a toroidal transformer and cascades of supercapacitors for the master clock 1, master clock 2, auxiliary clock, decimal display system, binary master display system, cross correlator and control board is installed.
Another analog power supply with a toroidal transformer and cascades of supercapacitors is installed for the original flywheel unit from the tri-axial inclination control system from the UKube-1 satellite as well as its servo controller.
THE DIMENSIONS AND WEIGHT
Diameter mm 1990, depth mm 149, weight kg 139
THE WARRANTY
20 years, non-transferable
THE MANUFACTURING
Schwyz at its best
THE PRICE
PERELMANseries, limited edition, CHF 971'000.- excl. VAT (production launch March 23st 2022 | introduction spring 2024)
RIEMANNseries, limited edition, CHF 937'000.- excl. VAT (production launch spring 2024 | introduction spring 2025)
OPTION: Module for high-frequency trading
An end-use / end-use statement is required for the export license (Tares 8543).
